KarbonCobra® – KC0

The KarbonCobra® KC0 sets a new standard for residential and pedestrian-scale roadway lighting, delivering up to 7,500 lumens with industry-leading efficiency of 165 lm/W. Engineered as a direct replacement for 50–150 W HID fixtures (70%+ energy savings), KC0 combines sleek design, low weight (only 5.9 lbs / 2.7 kg), and full smart-control readiness for instant plug-and-play connectivity. From neighborhood streets to parks and pathways, KC0 enhances safety, comfort, and sustainability while reducing energy and maintenance costs for years to come.

Features

  • 7-Pin Control-Ready Receptacle (Standard)
    Fully compatible with networked lighting controls (NLC) for future smart city and adaptive lighting deployments.
  • Optional Luminaire-Level IP54 Rating
    Enhanced protection against dust and moisture for demanding outdoor environments.
  • Up to 15 Performance Codes
    Multiple lumen and wattage configurations to precisely match roadway classification and project requirements.
  • Full Dimming Capability with PS Option
    Supports 2,000+ configurable output settings, enabling fine-tuned light levels for energy savings and visual comfort.
  • Rated for Ambient Temperatures up to 50°C
    Engineered for reliable operation in hot climates without performance degradation.
  • Die-Cast ADC1 Aluminum Housing
    High-strength, corrosion-resistant construction with excellent thermal management for long service life.
  • Single-Hand, Tool-Free Door Release
    Simplifies installation and maintenance, reducing service time and labor costs.
  • Improved Optical Performance
    Expanded distribution options deliver better roadway uniformity, coverage, and glare control.
  • Standard 3-Position Straight Terminal Block
    Provides secure, straightforward electrical connections for efficient field wiring.

Compact, efficient, and control-ready, the KarbonCobra® KC0 empowers cities and utilities to modernize their neighborhood lighting with a future-proof, cost-effective solution that delivers safer streets and smarter infrastructure—light by light.

Specifications

Series
KarbonCobra®
Application
Roadway & Street
Lumen Output
1200-7900
Color Temperture
2200K, 2700K, 3000K, 4000K, 5000K
Wattage
9-57 W
Distribution
Type II, Type III, Type V, Type IV
Mount Type
Pole Arm
Light Source
LED
CRI
70, 80
Voltage
120-277V / 347-480V
Dimming Control
Yes
Electrical Standard
UL

Resources

Download all

KarbonCobra - KC0

IES Files KC0
pdf

KC0-Spec-Sheet

Version: V5
Size: 928.15 KB
Hits: 44
Date added: 28-07-2025
Date modified: 10-11-2025
pdf

KarbonCobra-Sell-Sheet

Version: V1
Size: 1.74 MB
Hits: 21
Date added: 24-10-2025
Date modified: 10-11-2025
pdf

KarbonCobra-Installation-Guide

Size: 1.35 MB
Hits: 11
Date added: 22-04-2025
Date modified: 10-11-2025
pdf

KarbonCobra-Brochure

Version: 1
Size: 4.92 MB
Hits: 29
Date added: 05-08-2025
Date modified: 10-11-2025
pdf

Control Options Brochure

Size: 1.72 MB
Hits: 22
Date added: 07-11-2018
Date modified: 10-11-2025
