SafeGuard™ Utility Grade Light – UTL1

SafeGuard™ Utility Grade LED Security Light is a multi-purpose luminaire for Security, Dusk to Dawn, Street and Area Light applications. SafeGuard™ is a versatile, reliable, energy-efficient, and economical option for use in a wide range of scenarios.

Features

  • Standard version full cut-off requiring no supplemental shield
  • “DR” drop down refractor option for vertical illumination
  • Accepts industry standard NEMA refractor/reflector
  • Type 2, Type 3 and Type 5 light distributions for superior application efficiency
  • Dimmable driver standard
  • Surge protection standard. Optional 20kA/10kV and 10kA/5kA
  • 3 position terminal block standard
  • IP66 rated light engines
  • 3-pin photocontrol receptacle standard. Optional 7-pin
  • Stainless steel, captive, toolless door latches standard
  • Field installable light trespass shields available
  • Field controllable light output selector available
  • Field controllable color temperature filter available
  • Complete offering of mounting accessories
  • 2 hour burn-in and performance testing prior to shipment
  • 5-Year standard warranty

Specifications

Application Roadway & Street, Site & Area
Country North America
Dimming Control Y
Electrical standard UL
Lumen output 3071-7731
Series SafeGuard
Wattage 21-54
Color temperature 3000K, 4000K
CRI 70
Distribution Type Type II, Type III, Type V
Light Source LED
Mount Type Pole Arm
Voltage 120-277V / 347-480V

Resources

Product Specifications(1)
SafeGuard Utility Series Specification Sheet
May 19, 2024
|
708.56 KB
Supporting Documentation(2)
SafeGuard Utility Series Installation Guide
May 19, 2024
|
7.25 MB
SafeGuard Utility Series Lantern Brochure
May 19, 2024
|
5 MB
Accessories(4)
SafeGuard Color Filter Drawing
May 19, 2024
|
435.23 KB
SafeGuard Drop Down Refractor Lens Drawing
May 19, 2024
|
2.24 MB
SafeGuard Light Shield Drawing
May 19, 2024
|
396.82 KB
SafeGuard Mounting Accessories Drawings
May 19, 2024
|
3.68 MB
IES Files(8)
SafeGuard UTL-2 16J 3000K IES Files
May 19, 2024
|
197.12 KB
SafeGuard UTL-1 16J 3000K-HSS with DR IES Files
May 19, 2024
|
211.38 KB
SafeGuard UTL-2 16J 4000K IES Files
May 19, 2024
|
197.27 KB
SafeGuard UTL-2 16J 4000K with DR IES Files
May 19, 2024
|
7.74 MB
SafeGuard UTL-2 16J 3000K IES Files
May 19, 2024
|
197.12 KB
SafeGuard UTL-2 16J 3000K with DR IES Files
May 19, 2024
|
29.33 KB
SafeGuard UTL-2 16J 4000K IES Files
May 19, 2024
|
197.27 KB
SafeGuard UTL-2 16J 4000K with DR IES Files
May 19, 2024
|
7.74 MB
